Technical Details
More About this item
Technical Details
| Category | Specification |
|---|---|
| Model | DHI-LM25-E231B |
| LCD Technology | IPS |
| Backlight | ELED |
| Screen Size | 24.5 inch |
| Aspect Ratio | 16:9 |
| Resolution | 1920 (H) × 1080 (V) |
| Refresh Rate | 180 Hz |
| Display Color | 85% NTSC |
| Brightness | 300 cd/m² (max) |
| Contrast Ratio | 1000:1 |
| Viewing Angle | 178° (H) / 178° (V) |
| Display Mode | Horizontal |
| Response Time | MPRT 1 ms, OD 0.5 ms |
| Lifespan | 30,000 hours |
| Surface Treatment | Haze 25%, 3H |
| Input Ports | 1 × DisplayPort 1.4, 1 × HDMI 2.0 |
| Output Port | 1 × Audio Out |
More About this item
- Power Supply: 12 VDC, 3 A
- Power Type: External power adapter
- Power Consumption: 18 W (basic), 19 W (typical), 25.3 W (maximum)
- Standby Power Consumption: Less than 0.5 W
- Operating Temperature: 0 °C to +40 °C (32 °F to 104 °F)
- Operating Humidity: 10%–80% RH
- Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
- Storage Humidity: 5%–90% RH
- Inclined Angle: –5° ±2° / +20° ±2°
- Product Dimensions: 557.7 × 330.6 × 58.0 mm (W × H × D), without wall mount bracket
- Package Dimensions: 620 × 431 × 134 mm (W × H × D)
- Frame Width: Top/Left/Right 6.98 mm, Bottom 19.61 mm
- Net Weight: 2.93 kg
- Gross Weight: 4.0 kg
- Accessories Included: Power adapter, DisplayPort cable, user’s manual, legal and regulatory documents
- Wall Mount Support: VESA 100 × 100 mm
- Compliance: CE EMC, CE LVD, CE ERP, CB
